BB5100004 |
BINDING POST / DUAL / RED & BLACK THUMBSCREW / TRANSFORMERS |
1
|
$4.00/ea
|
|
|
|
IH5100003 |
BRACKET / ALUMINUM / FOR INDUCTORS / Z-4000 TRANSFORMER (Out of Stock) |
2
|
$8.00/ea
|
|
|
|
IH5100001 |
BRACKET / ALUMINUM / THROTTLE POTENTIOMETER MOUNT / Z-4000 TRANSFORMER (Out of Stock) |
3
|
$4.00/ea
|
|
|
|
IH5100002 |
BRACKET / FAN / Z-4000 TRANSFORMER (Out of Stock) |
4
|
$2.00/ea
|
|
|
|
IH5100004 |
BRACKET / FOR INDUCTORS & THROTTLE POTENTIOMETER / Z-4000 TRANSFORMER (Out of Stock) |
5
|
$8.00/ea
|
|
|
|
AD5100005 |
CAPACITOR BOARD / INPUT VOLTAGE FILTER / Z-4000 TRANSFORMER |
6
|
$15.00/ea
|
|
|
|
GG5100002 |
CASE / TOP / MOLDED PLASTIC / Z-4000 TRANSFORMER |
7
|
$75.00/ea
|
|
|
|
BB5100001 |
CIRCUIT BREAKER / 4A / RESETABLE / Z-500 / Z-750 / Z-4000 TRANSFORMER |
8
|
$7.00/ea
|
|
|
|
BB5100002 |
CIRCUIT BREAKER / 12A / RESETTABLE / Z-4000 TRANSFORMER |
9
|
$11.25/ea
|
|
|
|
AD5100002 |
CONNECTOR / UPGRADE MODULE JACK / Z-4000 TRANSFORMER |
10
|
$20.00/ea
|
|
|
|
BD5100001 |
COOLING FAN / 12VDC 1.2W / Z-4000 TRANSFORMER (Out of Stock) |
11
|
$20.00/ea
|
|
|
|
GG5100005 |
COVER / CAPACITOR BOARD / Z-4000 TRANSFORMER (Out of Stock) |
12
|
$3.00/ea
|
|
|
|
GG5100001 |
FACE PLATE / Z-4000 TRANSFORMER |
13
|
$6.00/ea
|
|
|
|
EG5100002 |
GEAR / THROTTLE POTENTIOMETER / Z-4000 TRANSFORMER |
14
|
$6.00/ea
|
|
|
|
BG5100002 |
INDUCTOR ASSEMBLY / Z-4000 TRANSFORMER |
15
|
$60.00/ea
|
|
|
|
GG5100004 |
INSULATOR PLATE / Z-4000 TRANSFORMER (Out of Stock) |
16
|
$2.00/ea
|
|
|
|
GG5100009 |
INSULATOR POST / Z-4000 TRANSFORMER (Out of Stock) |
17
|
$0.50/ea
|
|
|
|
GG5100006 |
NAME PLATE / SERIAL NUMBER / Z-4000 TRANSFORMER (Out of Stock) |
18
|
$5.00/ea
|
|
|
|
IC0000012 |
NUT / BINDING POST WIRE RETAINER / Z-4000 TRANSFORMER (Out of Stock) |
19
|
$0.50/ea
|
|
|
|
IC0000013 |
NUT / FLANGE / BINDING POST MOUNTING / Z-4000 TRANSFORMER (Out of Stock) |
20
|
$0.50/ea
|
|
|
|
IC0000014 |
NUT / BLACK / 4-40 (Out of Stock) |
21
|
$0.50/ea
|
|
|
|
IC0000011 |
NUT / THROTTLE POTENTIOMETER / Z-4000 TRANSFORMER (Out of Stock) |
22
|
$0.50/ea
|
|
|
|
AD5100004 |
PCB / BARRY BOARD / Z-4000 TRANSFORMER / ONLY USED IF SERIAL NUMBER STARTS WITH 0398 (Out of Stock) |
23
|
$10.00/ea
|
|
|
|
AD51000011 |
PCB / CONTROL BOARD / W/DIGITAL DISPLAY / 1st PRODUCTION RUN / Z-4000 TRANSFORMER (YELLOW WIRE BY TOP CENTER CHIP) / SERIAL NUMBERS BEGINING WITH 0398 ONLY |
24
|
$120.00/ea
|
|
|
|
AD51000012 |
PCB / CONTROL BOARD / W/DIGITAL DISPLAY / 2nd PRODUCTION RUN SERIAL NUMBERS BEGINING WITH 1198 OR HIGHER / Z-4000 TRANSFORMER (Out of Stock) |
24
|
$120.00/ea
|
|
|
|
CE5100001 |
PCB / RED LED / OVERLOAD INDICATOR / Z-4000 TRANSFORMER |
25
|
$8.00/ea
|
|
|
|
BI5100001 |
POTENTIOMETER / 10K OHMS / THROTTLE / Z-4000 (Out of Stock) |
26
|
$16.00/ea
|
|
|
|
BC5100007 |
POWER CORD / Z-4000 TRANSFORMER |
27
|
$14.00/ea
|
|
|
|
GG5100003 |
RUBBER PLUG / RJ-45 CONNECTOR / Z-4000 TRANSFORMER (Out of Stock) |
28
|
$3.00/ea
|
|
|
|
IA0000294 |
SCREW / PANHD / 4-40 x 0.785in L (Out of Stock) |
29
|
$0.25/ea
|
|
|
|
IA0000203 |
SCREW / PANHD / SELF-CUTTING / 10mm x 3mm |
30
|
$0.25/ea
|
|
|
|
IA0000057 |
SCREW / PANHD / SELF-CUTTING / 10mm x 3mm |
31
|
$0.25/ea
|
|
|
|
IA0000295 |
SCREW / WSHRHD / 3.3mm x 58mm / UNDERSIZED SHANK / BLACK (Out of Stock) |
32
|
$1.00/ea
|
|
|
|
IA0000133 |
SCREW / WSHRHD / SELF-CUTTING / 11.5mm x 3.3mm |
33
|
$0.25/ea
|
|
|
|
IA0000291 |
SCREW / PANHD / SELF-CUTTING / 4mm x 16mm / BLACK (Out of Stock) |
34
|
$0.25/ea
|
|
|
|
GG5100008 |
SPEC PLATE / Z-4000 TRANSFORMER (Out of Stock) |
35
|
$5.00/ea
|
|
|
|
BC5100006 |
STRAIN RELIEF / Z-4000 / POWER CORD |
36
|
$3.00/ea
|
|
|
|
GG5120001 |
THROTTLE HANDLE / BLACK / LH / Z-4000 |
37
|
$30.00/ea
|
|
|
|
GG5110002 |
THROTTLE HANDLE / BLACK / RH / Z-4000 TRANSFORMER |
38
|
$30.00/ea
|
|
|
|
EG5100001 |
THROTTLE HANDLE / GEAR / Z-4000 |
39
|
$10.00/ea
|
|
|
|
GG5120002 |
THROTTLE HANDLE COVER / BLACK / LH / Z-4000 |
40
|
$5.00/ea
|
|
|
|
GG5110001 |
THROTTLE HANDLE COVER / BLACK / RH / Z-4000 |
41
|
$5.00/ea
|
|
|
|
BG5100001 |
TRANSFORMER / Z-4000 TRANSFORMER (Out of Stock) |
42
|
$75.00/ea
|
|
|
|
ID0000082 |
WASHER / LOCK / 6.5mm O.D. x 3mm I.D. x 0.4mm THICK / NICKEL (Out of Stock) |
43
|
$0.25/ea
|
|
|
|
ID0000081 |
WASHER / LOCK / 7mm O.D. x 4mm I.D. x 1mm THICK / BLACK (Out of Stock) |
44
|
$0.25/ea
|
|
|
|
ID0000079 |
WASHER / LOCK / 8mm O.D. x 4.4mm I.D. x 0.6mm THICK / YELLOW ZINC (Out of Stock) |
45
|
$0.25/ea
|
|
|
|
ID0000078 |
WASHER / METAL / 15.7mm O.D. x 10.5mm I.D. x 0.7mm THICK (Out of Stock) |
46
|
$0.25/ea
|
|
|
|
ID0000080 |
WASHER / METAL / 6mm O.D. x 3mm I.D. x 0.8mm THICK / NICKEL (Out of Stock) |
47
|
$0.25/ea
|
|
|
|
BC5100003 |
WIRE HARNESS / 75mm L / 1 SHIELDED FEMALE CONNECTOR AND 1 RING TERMINAL / Z-4000 TRANSFORMER |
48
|
$3.00/ea
|
|
|
|
BC5100004 |
WIRE HARNESS / 75mm L / 2 SHIELDED FEMALE SPADE CONNECTORS / Z-4000 TRANSFORMER |
49
|
$3.00/ea
|
|
|
|
BC5100005 |
WIRE HARNESS / JUMPER WIRE / 4 RING TERMINALS / Z-4000 TRANSFORMER |
50
|
$3.00/ea
|
|
|
|
BC5100002 |
WIRE HARNESS / RIBBON CABLE / 10-WIRE / Z-4000 TRANSFORMER |
51
|
$8.00/ea
|
|
|
|
BC5100001 |
WIRE HARNESS / RIBBON CABLE / 26-WIRE / Z-4000 TRANSFORMER |
52
|
$10.00/ea
|
|
|
|
AD51000031 |
PCB / POWER BOARD / 1ST PRODUCTION RUN SERIAL NUMBERS BEGINING IN 0398 ONLY / Z-4000 TRANSFORMER (YELLOW WIRE BY 46 PIN BLACK PLUG) |
53
|
$200.00/ea
|
|
|
|
AD51000032 |
PCB / POWER BOARD / 2nd PRODUCTION RUN SERIAL NUMBERS BEGINING IN 1198 OR HIGHER / Z-4000 TRANSFORMER (5-POS PLUG ON TOP RH SIDE) |
53
|
$200.00/ea
|
|
|
|
CE5100002 |
PCB / POWER INDICATOR LED / GREEN / Z-4000 TRANSFORMER |
54
|
$8.00/ea
|
|
|
|
IA0000293 |
SCREW / WSHRHD / SELF-CUTTING / 25mm x 3.8mm |
55
|
$0.25/ea
|
|
|
|
IA0000292 |
SET SCREW / 0.4in x 5/16-18 |
56
|
$0.70/ea
|
|
|
|
IE0000048 |
SPRING / TENSION / W/POST / 6.1mm D x 20mm L / POST 4.4mm D x 11mm L / Z-4000 (Out of Stock) |
57
|
$1.00/ea
|
|
|
|
BB5100003 |
SWITCH / SPDT / LARGE / POWER ON & OFF / Z-4000 TRANSFORMER (Out of Stock) |
58
|
$8.00/ea
|
|
|
|
GG5100007 |
CASE / BOTTOM / BLACK / MOLDED PLASTIC / Z-4000 TRANSFORMER (Out of Stock) |
59
|
$86.00/ea
|
|
|
|
GG5200012 |
PUSH BUTTON / DPDT / MOMENTARY / BLACK / SQUARE / TRANSFORMERS (Out of Stock) |
|
$4.00/ea
|
|
|
|
GG5200007 |
PUSH BUTTON / DPDT / MOMENTARY / RED / SQUARE / TRANSFORMERS |
|
$4.00/ea
|
|
|
|
GG5200011 |
PUSH BUTTON / DPDT / MOMENTARY / RED / SQUARE / TRANSFORMERS / USE GG5200007 (Out of Stock) |
|
$4.00/ea
|
|
|
|
GG5200006 |
PUSH BUTTON / DPDT / MOMENTARY / WHITE / SQUARE / TRANSFORMERS |
|
$4.00/ea
|
|
|
|
GG5200009 |
PUSH BUTTON / DPDT / MOMENTARY / WHITE / SQUARE / TRANSFORMERS / USE GG5200006 (Out of Stock) |
|
$4.00/ea
|
|
|
|
GG5200005 |
PUSH BUTTON / DPDT / MOMENTARY / YELLOW / SQUARE / TRANSFORMERS |
|
$4.00/ea
|
|
|
|
GG5200010 |
PUSH BUTTON / DPDT / MOMENTARY / YELLOW / SQUARE / TRANSFORMERS / USE GG5200005 (Out of Stock) |
|
$4.00/ea
|
|
